NJEFG
HS 70193990
Yellow fiberglass mat is produced from chopped glass fiber by wet process. According to the different application, this product can be tailored as yarn reinforced, different size, individual packing and so on. With the features of fire proof, color fixation, high strength, abrasion resistance, and effective control of fiber scattering, yellow fiberglass tissue provides excellent fire-retardant, noise-reducing, heat insulation effects. The yellow fiberglass tissue is widely used as the surface layer of insulation board and also be used as idea insulation material of steel pipes.
Yellow fiberglass mat is produced from chopped glass fiber by wet process. According to the different application, this product can be tailored as yarn reinforced, different size, individual packing and so on. With the features of fire proof, color fixation, high strength, abrasion resistance, and effective control of fiber scattering, yellow fiberglass tissue provides excellent fire-retardant, noise-reducing, heat insulation effects. The yellow fiberglass tissue is widely used as the surface layer of insulation board and also be used as idea insulation material of steel pipes.
Excellent mechanical strength.
Fire proof and mildew proof.
Thermal insulation performance
Excellent mechanical strength.
Fire proof and mildew proof.
Thermal insulation performance
Product code | Unit Weight | LOI | MD Tensile Strength | CD Tensile Strength | Thickness | Moisture Content |
g/m2 | % | N/5CM | N/5CM | mm | % | |
F-DB25 | 25 | ≤25 | ≥ 80 | ≥50 | 0.2 | ≤ 1.0 |
F-DB35 | 35 | ≤30 | ≥ 150 | ≥70 | 0.30 | ≤ 1.0 |
F-DB40 | 40 | ≤30 | ≥180 | ≥80 | 0.35 | ≤ 1.0 |
F-DB45 | 45 | ≤30 | ≥ 200 | ≥90 | 0.35 | ≤ 1.0 |
F-DB50 | 50 | ≤30 | ≥250 | ≥100 | 0.40 | ≤ 1.0 |
Testing Basis | ISO3374 | ISO1887 | ISO3342 | ISO4603 | ISO 3344 | ISO 3344 |
Paper core diameter: 152mm |
Remark: 1. Other specification can be customized according to customer’s demand.
2. The technical data above is for reference only
Product code | Unit Weight | LOI | MD Tensile Strength | CD Tensile Strength | Thickness | Moisture Content |
g/m2 | % | N/5CM | N/5CM | mm | % | |
F-DB25 | 25 | ≤25 | ≥ 80 | ≥50 | 0.2 | ≤ 1.0 |
F-DB35 | 35 | ≤30 | ≥ 150 | ≥70 | 0.30 | ≤ 1.0 |
F-DB40 | 40 | ≤30 | ≥180 | ≥80 | 0.35 | ≤ 1.0 |
F-DB45 | 45 | ≤30 | ≥ 200 | ≥90 | 0.35 | ≤ 1.0 |
F-DB50 | 50 | ≤30 | ≥250 | ≥100 | 0.40 | ≤ 1.0 |
Testing Basis | ISO3374 | ISO1887 | ISO3342 | ISO4603 | ISO 3344 | ISO 3344 |
Paper core diameter: 152mm |
Remark: 1. Other specification can be customized according to customer’s demand.
2. The technical data above is for reference only
Insulation board veneer/ Glass wool board veneer/Ceiling back veneer/Solar flat panel collector veneer.
Glass wool duct lining.
Insulation board veneer/ Glass wool board veneer/Ceiling back veneer/Solar flat panel collector veneer.
Glass wool duct lining.
Shrink film, then in cartons or packed as customers' requirement.
Shrink film, then in cartons or packed as customers' requirement.
