PF1003/5
NJEFG
Polyester Fiberglass Composite Mat (Polyester Fiberglass Paving Mat) is produced from the mixture of polyester fiber and glass fiber by wet lay-out process. The combination of glass fiber and polyester fiber is the key to its performance. After mixing the two fibers together, the polyester fiberglass mat keeps good features of both fibers and minimizes shortcomings of both fibers.
Strong tensile strength make polyester-fiberglass composite mat especially suitable for waterproofing of payments; it extends the life of pavement through the delay of reflective cracking. Polyester fiberglass composite mat also serves as an effective moisture barrier. The unique, non-woven, polyester-fiberglass structure of the mat allows asphalt binder to fully penetrate and fill voids within the mat, limiting moisture infiltration and preventing water from infiltrating into the granular layers of the pavement structure.
Polyester- Fiberglass Composite Mat creates innovative solutions to help the paving projects to go smoothly and provides superior performance on airport runway, super highway, parking area and business lots.
Polyester Fiberglass Composite Mat (Polyester Fiberglass Paving Mat) is produced from the mixture of polyester fiber and glass fiber by wet lay-out process. The combination of glass fiber and polyester fiber is the key to its performance. After mixing the two fibers together, the polyester fiberglass mat keeps good features of both fibers and minimizes shortcomings of both fibers.
Strong tensile strength make polyester-fiberglass composite mat especially suitable for waterproofing of payments; it extends the life of pavement through the delay of reflective cracking. Polyester fiberglass composite mat also serves as an effective moisture barrier. The unique, non-woven, polyester-fiberglass structure of the mat allows asphalt binder to fully penetrate and fill voids within the mat, limiting moisture infiltration and preventing water from infiltrating into the granular layers of the pavement structure.
Polyester- Fiberglass Composite Mat creates innovative solutions to help the paving projects to go smoothly and provides superior performance on airport runway, super highway, parking area and business lots.
Strong tensile strength make polyester-fiberglass composite mat especially suitable for waterproofing of payments; it extends the life of pavement through the delay of reflective cracking. Polyester fiberglass composite mat also serves as an effective moisture barrier. The unique, non-woven, polyester-fiberglass structure of the mat allows asphalt binder to fully penetrate and fill voids within the mat, limiting moisture infiltration and preventing water from infiltrating into the granular layers of the pavement structure.
Polyester- Fiberglass Composite Mat creates innovative solutions to help the paving projects to go smoothly and provides superior performance on airport runway, super highway, parking area and business lots.
Strong tensile strength make polyester-fiberglass composite mat especially suitable for waterproofing of payments; it extends the life of pavement through the delay of reflective cracking. Polyester fiberglass composite mat also serves as an effective moisture barrier. The unique, non-woven, polyester-fiberglass structure of the mat allows asphalt binder to fully penetrate and fill voids within the mat, limiting moisture infiltration and preventing water from infiltrating into the granular layers of the pavement structure.
Polyester- Fiberglass Composite Mat creates innovative solutions to help the paving projects to go smoothly and provides superior performance on airport runway, super highway, parking area and business lots.
Item No. | Unit | PF1003/5 | PF136-600 |
Area Weight | g/m2 | 90-110 | 130-150 |
Tensile Strength MD | n/5cm | 220 | 300 |
Tensile Strength CD | n/5cm | 220 | 300 |
Polyester fiber content | % | 20-40 | 20-40 |
Glass fiber content | % | 50-70 | 50-70 |
Binder content | % | 15-25 | 15-25 |
Thickness | mm | 0.8 | ≤1.2 |
Melting point | ℃ | 230 | 230 |
Asphalt absorption capacity | L/m2 | 1.11 | |
elongation MD | % | <5 | <5 |
【Packaging】
Standard export packing for shipping.
1. Roll packaging: PE plastic film
2. Pallet packaging: Pallets should NOT be stacked in more than 2 layers.
Pallet is free of fumigation, fumigation certificate is available
【Storage】
This product should be stored in a dry, ventilated and rainproof place, with temperatures from 5℃to 35℃ and humidity between 35% and 65%. It is recommended to be kept in intact package when not used to avoid damp.
【Customization】
Materials in above table are the standard types Nanjing EFG CO., LTD is delivering to customers, if customer wants specific unit weight, tensile strength, roll width and roll length, Nanjing EFG CO., LTD can produce as per customer’s requirement, offer tailored service to customers from different countries.
【Loading】Standard export loading
【Markets】
Nanjing EFG CO., LTD. has delivered materials to USA, EU, Middle East, North Africa, South Africa, Asian customers with ensured quality and good feedback. Wiht rich experience for export and technical support, Nanjing EFG CO., LTD welcomes the cooperation with customers from all of the world.
【Delivery】
Materials will be loaded into container in factory, then be delivered to the sea port, finally be shipped to Customer’s port by MSK, MSC, CMA, COSCO, YANGMING, APL, etc.
【Payment】 LC, T/T, CAD, PAYPAL, WESTERN UNION, ETC.
【After sales service】
Nanjing EFG CO., LTD tracks cargo of every shipment till customer uses the materials, and offer any help for customer’s demand in any time.
【Technical support】
If customer meets any problem on technic, Nanjing EFG CO., LTD will supply relative knowledge to help customer find the best solution, and can send technician to customer’s factory for guiding if necessary.
Item No. | Unit | PF1003/5 | PF136-600 |
Area Weight | g/m2 | 90-110 | 130-150 |
Tensile Strength MD | n/5cm | 220 | 300 |
Tensile Strength CD | n/5cm | 220 | 300 |
Polyester fiber content | % | 20-40 | 20-40 |
Glass fiber content | % | 50-70 | 50-70 |
Binder content | % | 15-25 | 15-25 |
Thickness | mm | 0.8 | ≤1.2 |
Melting point | ℃ | 230 | 230 |
Asphalt absorption capacity | L/m2 | 1.11 | |
elongation MD | % | <5 | <5 |
【Packaging】
Standard export packing for shipping.
1. Roll packaging: PE plastic film
2. Pallet packaging: Pallets should NOT be stacked in more than 2 layers.
Pallet is free of fumigation, fumigation certificate is available
【Storage】
This product should be stored in a dry, ventilated and rainproof place, with temperatures from 5℃to 35℃ and humidity between 35% and 65%. It is recommended to be kept in intact package when not used to avoid damp.
【Customization】
Materials in above table are the standard types Nanjing EFG CO., LTD is delivering to customers, if customer wants specific unit weight, tensile strength, roll width and roll length, Nanjing EFG CO., LTD can produce as per customer’s requirement, offer tailored service to customers from different countries.
【Loading】Standard export loading
【Markets】
Nanjing EFG CO., LTD. has delivered materials to USA, EU, Middle East, North Africa, South Africa, Asian customers with ensured quality and good feedback. Wiht rich experience for export and technical support, Nanjing EFG CO., LTD welcomes the cooperation with customers from all of the world.
【Delivery】
Materials will be loaded into container in factory, then be delivered to the sea port, finally be shipped to Customer’s port by MSK, MSC, CMA, COSCO, YANGMING, APL, etc.
【Payment】 LC, T/T, CAD, PAYPAL, WESTERN UNION, ETC.
【After sales service】
Nanjing EFG CO., LTD tracks cargo of every shipment till customer uses the materials, and offer any help for customer’s demand in any time.
【Technical support】
If customer meets any problem on technic, Nanjing EFG CO., LTD will supply relative knowledge to help customer find the best solution, and can send technician to customer’s factory for guiding if necessary.
